Updated July 14/26
Blackmagic UltraStudio Series
Scroll down to see available options.
Blackmagic UltraStudio Express Monitor 3G - $239 - coming in mid-August
(BDLKULSDMBEXMON3G) The latest version of the hugely popular Blackmagic UltraStudio Monitor line, this time featuring USB4. Let’s you spit out a proper 10 bit 3G video signal from your video timeline (Resolve, Avid, Premiere, Final Cut, etc). to a television or broadcast monitor. The unit has one SDI 3G port and one HDMI 2.0 port for output. No AC Adapter is required as it takes power from the USB4 bus. SDI can output signals up to 2K DCI; the HDMI port can output up to 1080p60. NOTE – this box requires a native USB4 or ThunderBolt 4 or 5 port on your computer or it won’t work. Check your computer specs to make sure you have that. NOTE II – does not come with a USB4 or TBolt 4 cable. That is additional. Software drivers are required for the box to function. SYSTEM REQUIREMENTS – Mac 15 Sequoia, Mac 26 Tahoe or later. Windows 10 64 bit, Windows 11, or Linux. Warranty – 1 Year Canadian warranty.
Blackmagic UltraStudio Express Recorder 3G - $239 - coming mid-August
(BDLKULSDMAEXREC3G) The latest version of the popular Blackmagic UltraStudio Recorder line, this time featuring USB4. Let’s you capture a video signal either from a camera or a switcher into your computer. Very popular for livestreaming applications, such as Wirecast, vMix or OBS. This unit has one SDI 3G port and one HDMI 2.0 port for capture, with support up to 10 bit 4:4:4. Even though there are 2 ports, you cannot capture 2 signals at the same time – only one. NOTE – this box requires a native USB4 or ThunderBolt 4 or 5 port on your computer or it won’t work. Check your computer specs to make sure you have that. NOTE II – does not come with a USB4 or TBolt 4 cable. That is additional. Software drivers are required for the box to function. SYSTEM REQUIREMENTS – Mac 15 Sequoia, Mac 26 Tahoe or later. Windows 10 64 bit, Windows 11, or Linux. Warranty – 1 Year Canadian warranty.
Blackmagic UltraStudio 4K Mini - $1,625 - special order
(BDLKULSDMINI4K) UltraStudio 4K Mini is a portable Thunderbolt 3 capture and
playback solution packed with the latest broadcast technology!
You get broadcast quality 8 and 10‑bit high dynamic range
capture in all formats up to 4K DCI at 60p, and 12‑bit high
dynamic range capture in all formats up to 4K DCI at 30p.
Plus, the built in SD card reader lets you mount camera media
directly on your computer so you can start editing immediately!
Supported Codecs:
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC,
DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM
HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple
ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes
422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit
4:2:2, Uncompressed 10-bit 4:4:4.
Blackmagic UltraStudio HD Mini -
$845 - special order
(BDLKULSDMINHD) Compatible with Thunderbolt 3 computers only. Cable not included.
Features:
* SD/HD/3G-SDI and Analog Inputs
* HDMI and Dual SDI Outputs
* Thunderbolt 3 Interface
* Supports SD and HD Resolutions
* 4:2:2 and 4:4:4 Color Sampling Support
* 8/10/12-Bit Color Depth
* RS-422 Deck Control
* HD to SD Down-Conversion
(BDLKULSR4KEXTR/3) Advanced rack mount Thunderbolt and PCIe capture and playback for SD, HD, Ultra HD, and DCI 4K up to 60p, including 4:4:4 and dual channel 3D stereoscopic support. Features 12G-SDI and HDMI 2.0 so you can work with the latest high frame rate Ultra HD and 4K formats, along with analog video connections, timecode, analog XLR and AES/EBU audio, plus a built in hardware encoder for H.265 and ProRes on Mac OS X .
Find Decklink Studio products here
